Din rail single phase kWh meter, MID compliant, meet EU market. Impulse Constant is 1000imp/kWh, which means 1000 pluses is 1kWh. The meter is designed with a pulse indicator on the panel, and the user can easily judge the size of the power load by flashing the pulse indicator.
YTL DDS353 230V DIN Rail MID Approved Meter Solar PV application Suppliers
DDS353 MID
Contact Us
SPEC Download
YTL DDS353 230V DIN Rail MID Approved Meter Solar PV application
- Technical Parameters
- Measurements
- Meter Dimensions
- Diagram for installation
- det6
-
Content
Parameters
Standard:
EN50470-1/3
Rated Voltage:
230V
Rated Current:
0,25-5(30)A,0,25-5(32)A,0,25-5(40)A,
0,25-5(45)A,0,25-5(50)A
Impulse Constant:
1000 imp/kWh
Frequency:
50Hz/60Hz
Accuracy Class:
B
LCD Display:
LCD 5+2 = 99999.99kWh
Working Temperature:
-25～55℃
Storage Temperature:
-30~70℃
Power Consumption:
<10VA <1W
Average Humidity:
≤75% (Non Condensing)
Maximum Humidity:
≤95%
Start Current:
0.004Ib
LED flash:
Impulse indication, pulse width = 80 ms
-
Meter Type
Measurement
DDS353
kWh Total =Forward energy+Reverse energy
DDS353AF
KWh Total=Forward energy only
DDS353F+R
1 = kWh total ( forward + reverse)
2 = kWh (forward energy [import])
3 = kWh (reverse energy [export])
DDS353F-R
1 = kWh total (calculated by forward - reverse)
2 = V (Voltage)
3 = A (Ampere - current load)
4 = W (Watt - current active power)
5 = Hz (Frequency)
6 = PF (power factor)
DDS353AI
1 = kWh total ( forward + reverse)
2 = V (Voltage)
3 = A (Ampere - current load)
4 = W (Watt - current active power)
5 = Hz (Frequency)
6 = PF (power factor)
DDS353FI
1=Forward energy only
2= V (Voltage)
3= A (Ampere - current load)
4= W (Watt - current active power)
5= Hz (Frequency)
6 = PF (power factor)
DDS353F+R+I
1 = kWh total ( forward +reverse)
2 = kWh (forward energy [import])
3 = kWh (reverse energy [export])
4 = V (Voltage)
5 = A (Ampere - current load)
6 = W (Watt - current active power)
7 = Hz (Frequency)
8 = PF (power factor)
DDS353F-R-I
1 = Total Kwh（Forward - Reverse)
2 = Forwarder energy display
3 = reverse energy display
4 = V (Voltage)
5 = A (Ampere - current load)
6 = W (Watt - current active power)
7 = Hz (Frequency)
8 = PF (power factor)
-
-
-
