Prepaid-energy-meter cames into being due to frequent difficulties in recharging and was widely used, especially in Africa Market.
- According to the power purchase and recharge methods, prepaid meter can be divided into IC card smart prepaid meter and STS smart prepaid meter.
- According to the external structure, prepaid meter can be divided into wall mounted prepaid energy meter and din rail type prepaid energy meter.
- According to the power supply mode, prepaid meter can be divided into wall mounted type single phase prepaid meter, din rail type single phase prepaid energy meter, wall mounted type three phase prepaid energy meter, and din rail type three phase prepaid energy meter.
STS prepaid meter is the most popular in Africa Market, complies with STS standard transmission specifications. Currently, this specification is the only globally recognized open standard for prepaid systems with very high security. Recharge by entering the code on the keypad, there is no recharge medium and more convenient to use.
There is a processes for the use of STS prepaid meter, and today I will share with you a few key point.
1. How does prepaid meter work?
Prepaid meter needs to be recharge then it can work. When run out of the purchase electricity, it will automatically disconnect the relay and cut off power supply.
2. How to register my prepaid meter? How to active prepaid meter?
STS prepaid meter has a test code when it out of factory, and is necessary to enter the local token code then register and active the prepaid meter.
3. How to recharge the prepaid meter?
First, purchase electricity at prepaid meter recharge outlets, will generate a 20-digital token code. Then enter the code through the keypad on the prepaid meter surface board, prepaid meter can be recharged successfully.
4. How to check the balance of prepaid meter?
l using the display page turning button on the prepaid meter
l Enter the code #009# through keypad on the prepaid meter
5. How to credit a prepaid meter?
When run out of electricity, prepaid meter will automatically cut of the power supply. But there has a humanized detail design, to prevent the purchase of electricity from running out at night, you can credit a certain amount of electricity, enter the code #444#.
6. How To Reset Prepaid Meter?
Create a reset token through sts vending software, then enter the code into prepaid meter.
l Initialization
Professional host computer software is required to issue initialization commands to the meter to complete reset.
Prepaid meter of YTL metering with many type and specifications, such as wall mounted Type Single Phase STS prepaid meter, Din Rail Type Single Phase STS Prepaid Meter, wall mounted Type Three Phase STS Prepaid meter, Din Rail Three Phase STS prepaid meter. Mainly exported to African countries, well recognized by customers.
