The Future Potential Of Three Phase Smart MID Meters!

The future potential of three phase smart MID meters!



Smart meter is an important part of smart grid. It is composed of measurement unit, data processing unit and communication unit. It can realize electric energy measurement, information storage and processing, real-time monitoring, automatic control, information interaction and other functions. It is applied to smart grid, electric automobiles, microgrids, automatic lighting, smart devices,etc.







What are the functions of YTL Metering 's three phase MID smart meters? Why are these functions necessary? Can it be used in the above application scenarios?

Here are the answers one by one.



What are the functions of YTL Metering 's three phase MID smart meters?



  1. Measurement function
  2. Communication
  3. Display
  4. Button
  5. Pulse output





Why are these functions necessary?

  • Measurement function, as an electricity meter, the most basic function is the metering function, but the difference between smart meters and ordinary meters is also metering. Smart meters have two way (Bi-directional) metering and can set multiple rates at the same time.
  • It has three phase active/reactive energy, positive and negative measurement, four tariffs.
  • It can be set three measurement modes according to the synthesis code.
  • CT setting: 5:5—7500:5 CT ratio.
  • Maximum demand calculation.
  • Touch button for scrolling pages.
  • Holiday Tariff and Weekend Tariff Setting.
  • Communication function, as the most important component of the smart meter to connect to the smart grid, it can communicate and feed back data information in real time.
  • It supports IR(near infrared) and RS485 communication. IR complies with IEC 62056 (IEC1107)protocol, and RS485 communication use the MODBUS protocol.
  • Display function can display information to the user in real time.
  • It can display the total energy, tariff energy, three phase voltage, three phase current, total/three phase power, total/three phase apparent power, total/three phase power factor, frequency, CT ratio, pulse output, communication address, and so on(details please see the display instruction).
  • Button,press the button to select the display content through the button. At the same time, you can also set the CT ratio, LCD scroll time, and reset the battery by pressing the button.
  • The meter has two buttons, it can be displayed all the contents by pressing the buttons.

Meanwhile, by pressing the buttons, the meter can be set the CT ratio, LCD scroll display time.

  • It can be set the automatic display contents through IR.
  • Pulse output, the value represents the number of times the pulse light of the electric meter flashes for each kilowatt hour of electricity used.
  • Set 12000/1200/120/12, total four pulse output modes by communication.



Can it be used in the above application scenarios?



YTL Metering is a very mature and professional manufacturer of smart meters. The meters produced meet various application scenarios, especially for the booming electric vehicle charger industry chain. YTL Metering launched three phase MID smart meters that can be used for quick charger the market is the product that currently leads the market!

If you are interested in our electric energy meters, please contact us!
