As a key component of modern power system, intelligent power monitoring device has various and complex functions, which aims to realize real-time monitoring, early warning, control and management of power system, to improve the operational efficiency and security of the system. Here are the main features of smart power monitoring devices:

1. Real-time monitoring

.11. Data Acquisition: The Intelligent Power Monitoring Device uses the communication interface and protocol to collect the electrical parameters and switching status of the field equipment in real time through the front host, including three-phase voltage, current, power, frequency, temperature, switch position, power factor, power and so on. The real-time collection of these data provides detailed information support for the operation of power system.

1.2. Monitoring Scope: the device can cover the important distribution circuit, equipment, environmental monitoring, video monitoring and other aspects of the distribution room to achieve all-round, all-weather real-time monitoring.

2. intelligent diagnosis and early warning function

2.1. Fault early warning: Based on the real-time data, the intelligent power monitoring device can make intelligent diagnosis, find out the abnormal condition of the equipment and give early warning. For example, when an associated electrical limit is detected, the associated relay will output an alarm signal to inform operations staff for processing.

2.2. Fault diagnosis: by analyzing the operation data, the system can assist the operation personnel to diagnose the fault, locate the fault location, reduce the time of troubleshooting and improve the operation efficiency.

3. Remote control function

3.1. Remote control operation: users can remote control power equipment through the network to achieve switching, regulating and other functions. This remote control function reduces the on-site inspection workload of operation and maintenance personnel and improves the operation and maintenance efficiency.

3.2. Remote Maintenance: the intelligent power monitoring device supports remote maintenance and upgrading. The operation and maintenance personnel can set the parameters and update the software through remote operation, thus reducing the maintenance cost.

4. Data Analysis and management function

4.1. Data storage and analysis: the system has data storage and analysis functions, can generate reports, trend analysis charts and so on, to provide data support for operation and maintenance decision-making. By analyzing the operation data of the equipment, the system can help the operation and maintenance personnel make more reasonable maintenance plan, prolong the service life of the equipment and reduce the maintenance cost.

4.2. Report management: the system provides real-time running report and history report, which dynamically compares and monitors the voltage, current, power and other electric parameters of each circuit History Report provides data inquiry and statistical function, such as daily report, Monthly Report, Quarterly Report, annual report, etc. .

5. Environmental and safety monitoring functions

5.1. Environmental Monitoring: the intelligent power monitoring device can connect with environmental monitoring sensors such as temperature and water immersion to monitor the environmental status of the power distribution room in real time and provide environmental information support for the operation and maintenance personnel.

5.2. Safety Monitoring: the system supports access to fire detectors, such as smoke and temperature sensors, and devices such as access control and camera, to realize safety monitoring and personnel management in the distribution room.

6. User interface and interactive functions

6.1. Graphical Presentation: through the monitoring software, the intelligent electric power monitoring device realizes the graphical presentation effect, and displays the running status of the field equipment and the real-time status monitored by the graphic way.

6. 2. Various Interactive modes: the system provides various interactive modes, such as WEB management background, mobile phone APP, on-site touch screen, etc. .

7. Extensibility and compatibility

7.1. Expandability: the intelligent power monitoring device has good expandability, which can be easily connected to new devices and sensors to meet the changing monitoring needs.

7.2. Compatibility: the system supports multi-protocol docking, which can seamlessly connect power platform and other related systems, and realize information sharing and interworking.

The above functions together constitute the core competitiveness of the intelligent power monitoring device, which provides a strong guarantee for the safe and stable operation of the power system.
