Rigid Rogowski Coil
Powering Modern Energy Metering

Discover YTL's rigid Rogowski current-sensing technology and its integration into modern power metering systems.

Rigid Rogowski Coil Integrated Metering Connected Energy Data

Modern Power Systems Are Changing Current Measurement

01 / POWER FLOW
Two-Way Power

Two-Way Power

Solar PV, battery storage and EV charging make power flow bidirectional. Both import and export must be measured.

02 / DYNAMIC LOADS
Faster Loads

Faster Loads

Fast-changing charging and power-conversion loads demand measurement that can capture changing current conditions.

03 / POWER QUALITY
Power Quality

Power Quality

Non-linear loads can distort waveforms. Better visibility into harmonics and transients becomes increasingly important.

04 / MORE NODES
More Channels

More Channels

More circuits and distributed assets call for scalable measurement across main feeders and branch circuits.

YTL Power Sensing & Metering Architecture

01 / CURRENT SENSING
YTL rigid Rogowski coil mounted on a copper busbar

Current Sensing

YTL rigid Rogowski coils provide coreless, saturation-free current sensing with wideband response and stable mechanical positioning for precision measurement.

THE SENSING FOUNDATION
02 / METERING
Metering & Data Acquisition

Metering & Data Acquisition

YTL metering options support zero-export monitoring, fast data response and power quality analysis, depending on the product model. Multi-circuit metering is under development.

MEASURE WITH PURPOSE
03 / CONNECTIVITY
Connectivity & Edge

Connectivity & Edge

RS485, M-Bus, Wi-Fi and 4G communication options support integration with compatible metering and energy management systems, depending on product configuration.

CONNECT THE MEASUREMENT
04 / DATA APPLICATIONS
Platform / AI Interface

Platform / AI Interface

Measurement data can support monitoring, visualization and energy management applications. Advanced anomaly detection and predictive maintenance are future development directions.

TURN DATA INTO INSIGHT
An integrated approach to current sensing, metering and energy data applications.

Four Measurement Challenges.
Four YTL Solutions.

YTL combines current sensing with purpose-built metering products to address different measurement requirements across modern electrical systems.

M60313-9194 WiFi / Bluetooth Anti-Export Energy Meter

01 / BIDIRECTIONAL POWER FLOW

WiFi / BT Anti-Export Meter

M60313-9194

For applications requiring accurate measurement and control of bidirectional energy flow, including solar and energy storage systems.

M60313-9195 4G Anti-Export Energy Meter

02 / REMOTE ENERGY MONITORING

4G Anti-Export Meter

M60313-9195

For remote solar, energy storage and EV charging installations requiring bidirectional energy measurement and 4G connectivity.

M60333 High-Refresh Energy Meter

03 / FASTER-CHANGING LOADS

High-Refresh Energy Meter

M60333

For applications where responsive measurement is important, including EV charging, power electronics and dynamic loads.

M30333 Power Quality Analyzer

04 / POWER QUALITY

Power Quality Analyzer

M30333

For electrical measurement and power quality analysis, providing greater visibility into electrical system performance.

One sensing foundation. Multiple metering applications. The rigid Rogowski coil is the current-sensing foundation within a broader YTL power sensing and metering portfolio.

A New Approach to Current Sensing.

Rigid Rogowski technology combines a coreless sensing principle with a defined mechanical structure — bringing wideband response and controlled installation geometry to modern power measurement.

YTL R10S rigid Rogowski current sensor

CORELESS SENSING · RIGID CONSTRUCTION

Designed for measurement performance and practical integration.

Unlike conventional magnetic-core CTs, the Rogowski sensing element has no magnetic core and does not experience magnetic-core saturation. Its rigid construction helps define the coil geometry and supports repeatable installation. Split-core and closed-core configurations are available for different conductor and installation requirements.

01 / SATURATION

No Magnetic Saturation

Coreless sensing avoids magnetic-core saturation and supports a wide current measurement range.

02 / FREQUENCY

Wideband Response

Measured frequency response from 10 Hz to 80 kHz under the stated test conditions.

03 / ENVIRONMENT

Environmental Adaptability

Rigid construction supports demanding installation environments, with high environmental adaptability in the comparison shown.

04 / DC COMPONENT

DC Component Resistance

Rogowski sensing is not affected by DC current components in the same way as magnetic-core CTs.

05 / AC FIELD

AC Magnetic Field Resistance

The rigid Rogowski configuration demonstrates resistance to alternating magnetic-field interference in the comparison presented.

06 / DC FIELD

DC Magnetic Field Resistance

Coreless sensing avoids magnetic-core effects associated with external DC magnetic fields.

Rigid Rogowski Coil Product Series

IEC 61869-10 · CLASS 0.2 PERFORMANCE

YTL R10S standard-series rigid Rogowski coil

Standard Series · R10S

Split-core: 125 A / 300 A / 500 A
Designed for flexible integration across standard current measurement applications.

YTL high-accuracy rigid Rogowski coil

High-Accuracy Series · R20S / R20C

Split-core: 200 A / 400 A / 600 A
Closed-core: 400 A / 600 A / 800 A / 1200 A / 2400 A.
