Features
Modular structure,Modular structure, can flexibly form various voltage platforms and systems with various capacity levels within 1500V, easy to maintain
Using lithium iron phosphate battery, high safety performance, long cycle life, design life more than 15 years
BMS Core research and development capabilities
Power system integration capability
Accumulated different types of energy storage customers
PACK, BMS independent research and development and production, delivery time is controllable
Mature pre-sales and after-sales team and on-site support capabilities
|
 |
 |
|
| 38.4V 280AH | 38.64V 346AH | 28.8V 240AH | |
| Serial and parallel | 1P12S | 2P12S | 6P9S |
| Voltage range | 30〜43.8V | 30〜43.8V | 22.5〜32.85V |
| Recommended charging and discharging current | 140A | 173A | 240A |
| Max charge and discharge current | 280A | 346A | 480A |
| Max working temperature | -20°C〜+55°C | -20°C〜+55°C | -20°C〜+55°C |
| Design life | >10year | >10year | >10year |
| Cycles(0.5c) | 5000@25°C | 5000@25℃ | 5000@25℃ |
| Weight | 73kg | 87kg | 67kg |
| Protection level | IP20 | IP20 | IP20 |
| dimensions (mm) | 478×554×224 | 600×454×224 | 600×544×162 |
| Standard | UN38.3/UL1973 /UL9540A | UN38.3/UL1973 /UL9540A | UN38.3/UL1973 /UL9540A |
https://www.ytl-e.com/contact/
Established in 2000, Zhejiang Yongtailong Electronic Co., Ltd. is located in the center of Shanghai, Hangzhou and Suzhou cities. YTL is a professional China 22.5〜32.85V Energy storage standard battery Suppliers and 22.5〜32.85V Energy storage standard battery Company. With more than 20 years of energy metering experience, we devote ourselves to providing competitive projects and creating value for customers. YTL was one of the first companies in the domestic market with which had an internal R&D department as well as international sales business. Since our foundation in 2000 we have grown to a manufacturer which complies and meet to many specifications from our national and international partners. At present our export volume makes us a leading company for technology and product export to more than 50 countries throughout the world. With provincial high-tech enterprise R&D center, YTL is the Top 100-enterprise with most investment value in Zhejiang. And“Yongtailong”is the famous brand of Zhejiang. For any new products of customers, we will communicate with customers very professionally, listen to their opinions and give useful suggestions to ensure that excellent quality products are made.
